MaxLinc BLOCK Fluid Pressure & Temp

The BLOCK Fluid Pressure and Temperature monitoring solution provides precise measurements of fluid pressure and temperature, along with real-time alarms for various applications. It also records ambient temperature and humidity and features two external ports for a flood sensor and a programmable digital input, which can function as a cumulative pulse counter or digital input alarm. With the ability to report pressure in H2Omm (in addition to MPa and PSI), it is an excellent choice for depth monitoring in tanks, eliminating the need to insert components into the tank or access its top. Pressure sensor range must be selected when ordering, as it is permanently integrated into the device and cannot be changed later, ensuring accuracy and reliability for specific applications. This versatility makes it suitable for a wide range of environments. Available pressure ranges: 0 to 5 bars (0 to 0.1 MPa = 100 Kpa) - Part Number: BLTPRS-0100 Suitable for water tank depth measurement (up to 10 meters) 0 to 5 bars (0 to 0.25 MPa = 250 Kpa) - Part Number: BLTPRS-0250 Suitable for water tank depth measurement (up to 25 meters) 0 to 5 bars (0 to 0.5 MPa = 500 Kpa) - Part Number: BLTPRS-0500 0 to 10 bars (0 to 1 MPa = 1000 Kpa) - Part Number: BLTPRS-001K Suitable for city water supply pressure 0 to 20 bars (0 to 2 MPa = 2000 Kpa) - Part Number: BLTPRS-002K 0 to 50 bars (0 to 5 MPa = 5000 Kpa) - Part Number: BLTPRS-005K 0 to 100 bars (0 to 10 MPa = 10000 Kpa) - Part Number: BLTPRS-010K
